Description
OptoSpan 220m SFP+ transceiver for 10G LRM Ethernet. 10Gb SFP+ 1310nm transceiver for multimode fiber. Details: This advanced 3.5dB transceiver is designed for highly reliable fiber optic network links up to 220m. Using FP+PIN technology, it operates at a nominal wavelength of 1310nm coupled to an LC optical connector. It is a cost effective transceiver designed to enable 10Gb for data center and core network applications. The SPP-81D-M220T31 offers enhanced digital diagnostics for real-time monitoring of transceiver performance. The module is designed to strictly comply with well known SFP+ specifications developed by the SFF committee. This module is RoHS compliant and lead-free. OptoSpan 10Gb Standard optical transceivers are compatible with many brands such as Finisar, Avago, JDSU and network environments that do not require any special compatibility. For networks that require special OEM compatibility, such as CISCO, BROCADE, JUNIPER, ALCATEL, HP, NORTEL, EMC, QLOGIC and other OEMs, consider OptoSpan Platinum OEM Series transceiver model# PSPP-81DT31M220.
Click Here for additional information on OptoSpan 10G SFP+ Transceivers.
Key Features:
- 10GBASE-LRM Ethernet 3.5dB SFP+ Transceiver
- 220m LRM SFP+ for MMF @ 10Gbps
- 1310nm FP+PIN Laser 220m SFP+
- -0°C – 70°C Temperature – Extended/Industrial Available
- 2-Wire Interface Digital Diagnostic Monitoring (SFF-8724)
- Hot-swappable for SFP+ LC ports
- OptoSpan 1 year standard warranty
- Use with Finisar, Avago, JDSU & networks not requiring OEM compatibility
- Compliant with SFF-8431, SFF-8432
- RoHS compliant
Applications:
- 10GBASE-LRM @ 10.31Gbps
- 10 Gigabit Ethernet
- Fibre Channel 8x
- Fibre Channel 4x
OptoSpan 220m SFP+ transceiver for 10G LRM Ethernet. 10Gb SFP+ 1310nm transceiver for multimode fiber.
SPP-81D-M220T31 Datasheet
