Description
OptoSpan 10 km Single Fiber XFP SONET/SDH transceiver for 10G LR SONET OC-192 / STM-64 w/ CDR. Cisco Compatible single strand bidirectional XFP SONET/SDH transceiver. Details: This advanced 9dB transceiver is designed for highly reliable fiber optic network links up to 10 km. Using DFB+PIN technology, it operates at a nominal wavelength of 1270Tx-1330Rx coupled to an LC optical connector. It is a cost effective transceiver designed to enable 10Gb for data center and core network applications. The PXFS-10GB27K010 offers enhanced digital diagnostics for real-time monitoring of transceiver performance. The module is designed to strictly comply with well known XFP specifications developed by the SFF committee. This module is RoHS compliant and lead-free. OptoSpan 10Gb Single Fiber series transceivers have undergone rigorous qualification and certification testing to provide End-to-End Compatibility using switching equipment from CISCO, BROCADE, JUNIPER, ALCATEL, HP (select models), NORTEL, EMC, QLOGIC and other OEMs.
Click Here for additional information on OptoSpan Single Fiber XFP Transceivers.
Key Features:
- Exclusive Japanese OSAs for Ultimate Reliability
- SONET OC-192 / STM-64 w/ CDR 9dB SONET/SDH XFP Transceiver
- 10 km LR SONET/SDH XFP for SMF @ 10Gbps
- 1270Tx-1330Rx DFB+PIN Laser 10 km SONET/SDH XFP
- -0°C – 70°C Temperature – Extended/Industrial Available
- 2-Wire Interface Digital Diagnostic Monitoring (SFF-8724)
- Extended 2 Years Warranty
- Tested and Certified in Brand Specific Networks and Target Applications
- Assembled Using Highest Quality Raw Components
- XFP MSA, IEEE 802.3ae & ROHS
Applications:
- SONET OC-192 / SDH STM-64
- 10 Gigabit Fibre ChannelOTN ITU-T G.709
- 10GBASE-LR @ 10.31Gbps
- 10GbE & 10Gb/s FC w/FEC
OptoSpan 10 km Single Fiber XFP SONET/SDH transceiver for 10G LR SONET OC-192 / STM-64 w/ CDR. Cisco Compatible single strand bidirectional XFP SONET/SDH transceiver.
PXFS-10GB27K010 Datasheet
