SFP+ DWDM 40 km transceiver | 10G ER Ethernet

Description

OptoSpan 40 km DWDM SFP+ transceiver for 10G ER Ethernet. 10Gb SFP+ transceiver for single-mode fiber. Details: This advanced 14dB transceiver is designed for highly reliable fiber optic network links up to 40 km. Using EML+PIN technology, it operates at a nominal wavelength of 50GHz (C-Band) coupled to an LC optical connector. It is a cost effective transceiver designed to enable 10Gb for data center and core network applications. The SPP-81D-K040XXX offers enhanced digital diagnostics for real-time monitoring of transceiver performance. The module is designed to strictly comply with well known SFP+ specifications developed by the SFF committee. This module is RoHS compliant and lead-free. OptoSpan 10Gb DWDM optical transceivers are compatible with many brands such as Finisar, Avago, JDSU and network environments that do not require any special compatibility. For networks that require special OEM compatibility, such as CISCO, BROCADE, JUNIPER, ALCATEL, HP, NORTEL, EMC, QLOGIC and other OEMs, consider OptoSpan Platinum OEM Series transceiver model# PSPP-81DXXXK040.

Click Here for additional information on OptoSpan DWDM SFP+ Transceivers.

Key Features:

• 10GBASE-ER/EW Ethernet 14dB SFP+ Transceiver
• 40 km ER SFP+ for SMF @ 10Gbps
• 50GHz (C-Band) EML+PIN Laser 40 km SFP+
• -0°C – 70°C Temperature – Extended/Industrial Available
• 2-Wire Interface Digital Diagnostic Monitoring (SFF-8724)
• Hot-swappable for SFP+ LC ports
• OptoSpan 1 year standard warranty
• Use with Finisar, Avago, JDSU & networks not requiring OEM compatibility
• Compliant with SFF-8431, SFF-8432
• RoHS compliant

Applications:

• 10GBASE-ER @ 10.31Gbps
• 10 Gigabit Ethernet
• Fibre Channel 8x
• Fibre Channel 4x

OptoSpan 40 km DWDM SFP+ transceiver for 10G ER Ethernet. 10Gb SFP+ transceiver for single-mode fiber.
