Description
Single-mode (OS2) MPO(Male)-MPO(Male) 12 Fiber IP68-MPO Weatherproof Cable. Use this 9/125 OS2 (Yellow) IP68-MPO Weatherproof Cable for 10G/100G fiber networks.
IP68 Rated MPO Fiber Optic Connectivity System with Sealed Bayonet Locking for Industrial and Harsh Environments.
OptoSpan ruggedized IP68-MPO Weatherproof Fiber Cables allow for the installation of high performance fiber optics in environments previously believed to be too harsh due to chemical, corrosive gases, dust and water exposure. Suitable for harsh environments, it is the ideal fiber optic connectivity solution for LTE, DAS, or Mobile Cell Towers (FTTA) implementations.
To protect the internal fiber from exposure to the elements, each assembly of OptoSpan IP68-MPO fiber cable is equipped with ODVA compliant sealed bayonet locking MPO connectors. This bayonet mechanism seals the delicate fiber inside to withstand elements of the harsh environment such as extreme temperatures, water exposure as well as chemical vulnerability.
For flexibility in harsh environment network design, OptoSpan also offers In-Line adapters for fiber cable extensions, bulkhead adapters for enclosures, and high grade adapter dust caps to protect the adapters. If extra network security is required, OptoSpan IP68-MPO fiber cables can be upgraded with an add-on SafetyRing locking system that will safeguard the housing in its place and reduce the opportunity for undue tampering with network connections.
IP68-MPO Cables Exclusive Features:
- IP68 Water immersion and Dust protection
- Simple bayonet assembly requiring no special tools
- Tamperproof Color Coded SafetyRing Locking System
- Low Insertion loss – .10dB for Single-mode
- Sealed Cell Tower Junction Boxes Available
- Factory Certified and 100% tested for superior performance
(Optional) IP-68 Plug and Play MPO-LC Fan-Out kits allows for multi-fiber assemblies to be securely configured without the threat of contamination from the harsh elements. These comprehensive kits allow quick and repeatable connectivity between the Fan-Out, main feeder and jumper leads.
Optional MTP Elite (US Conec) low loss connectors available.
Key Features:
- IP68-MPO Weatherproof Cable
- MPO(Male)-MPO(Male) Connectors
- 12 Fiber
- Single-mode Communication
- Color – Yellow
- OS2 Standard
- 9/125 µm Core Diameter
- OFNR (Riser) Rated
- 1m – 500m in length
PXPX-KS212WXRXX* – *Replace last two letters “XX” with a Cable Length Code. All lengths are in Meters. Valid Codes: 01, 02, 03, 05, 07, 10, 15, 20, 25, 30, 40, 50, 60, 75, 0C (100m), CD (125m), CL (150m), CC (200m), 3C (300m), 0D (500m)
